Model：ATZTA VN
Nominal diameter：5mm（R1/4）･10mm（R1/2）･20mm（R1）
Standards certification：RoHS、CE、UKCA
Model VN is the cost-saving electromagnetic flow sensor that is compact and does not require any straight pipe length so that it can be easily built in the machines and devices. Due to its excellent small flow-rate measurement and repeatability, it has merits in various applications such as pesticide spraying agricultural drone, milk feeding machine for calves, medical cleaning equipment, Foam (CAFS) type firefighting vehicle, remaining amount management of beer server’s tank, 3D metal printer, etc..png)
Nominal diameter：5mm（R1/4）･10mm（R1/2）･20mm（R1）
Standards certification：RoHS、CE、UKCA
Model VN is the cost-saving electromagnetic flow sensor that is compact and does not require any straight pipe length so that it can be easily built in the machines and devices. Due to its excellent small flow-rate measurement and repeatability, it has merits in various applications such as pesticide spraying agricultural drone, milk feeding machine for calves, medical cleaning equipment, Foam (CAFS) type firefighting vehicle, remaining amount management of beer server’s tank, 3D metal printer, etc.
- With absence of moving parts, there is less failure due to its contaminants
- Closely no pressure loss and excellent durability
- Reduced cost as a result of limiting necessary functions design
- Compact design, easy to install
- Piping with both straight and bended is available.
- As this flowsensor has 2 contact outputs, various functions are selectable
- Frequency pulse output (Span frequency is selectable)
- Unit pulse output
- Abnormal condition detection is displayed by LED in top face of sensor main body
- Switch output (Level judgment/window judgment is available)
